LAEN11 | Auxiliary contact block, EasyPact TVS, 1NO+1NC
| brands | Schneider Electric |
|---|---|
| Range | EasyPact |
| Device application | Signalling |
| Product or component type | Auxiliary contact block |
| Device short name | LAEN |
| Contacts operation | Instantaneous |
| Pole contact composition | 1 NO + 1 NC |
| Irms rated making capacity | 140 A AC conforming to IEC 60947-5-1 |
| Mechanical durability | 10 Mcycles |
| Minimum switching current | 5 mA |
| Insulation resistance | > 10 MOhm |
| Non-overlap time | 1.5 ms on energisation no overlap between NC and NO contact 1.5 ms on de-energisation no overlap between NC and NO contact |
| Range compatibility | EasyPact (EasyPact TVS) LC1E |
| Mounting location | Front |
| Auxiliary contacts operation | Instantaneous |
| minimum switching voltage | 17 V |
| Colour | Grey (RAL 7011) |
| Product certifications | GOST |
| Net weight | 0.035 kg |
| Environmental characteristic | Standard environment |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.1 cm |
| Package 1 Width | 4.8 cm |
| Package 1 Length | 7.1 cm |
| Package 1 Weight | 34.0 g |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 100 |
| Package 2 Height | 15.0 cm |
| Package 2 Width | 30.0 cm |
| Package 2 Length | 40.0 cm |
| Package 2 Weight | 3.751 kg |
| REACh Regulation | REACh Declaration |
| EU RoHS Directive | Compliant EU RoHS Declaration |
| China RoHS Regulation | China RoHS declaration Product out of China RoHS scope. Substance declaration for your information |
| Environmental Disclosure | Product Environmental Profile |
| Circularity Profile | No need of specific recycling operations |
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 18 months |
