XB4BK133M5 | Illuminated selector switch, metal, green, Ø22, 3 positions, stay put, 230…240 V AC, 1 NO + 1 NC
| brands | Schneider Electric |
|---|---|
| Range of product | Harmony XB4 |
| Product or component type | Illuminated selector switch |
| Device short name | XB4 |
| bezel material | Chromium plated metal |
| contacts usage | Standard contacts |
| Positive opening | With conforming to IEC 60947-5-1 appendix K |
| Mechanical durability | 500000 cycles |
| Tightening torque | 0.8…1.2 N.m conforming to IEC 60947-1 |
| Shape of screw head | Cross compatible with Philips no 1 screwdriver Cross compatible with pozidriv No 1 screwdriver Slotted compatible with flat Ø 4 mm screwdriver Slotted compatible with flat Ø 5.5 mm screwdriver |
| Contacts material | Silver alloy (Ag/Ni) |
| Short-circuit protection | 10 A cartridge fuse type gG conforming to IEC 60947-5-1 |
| [Ui] rated insulation voltage | 600 V (pollution degree 3) conforming to IEC 60947-1 |
| Device presentation | Complete product |
| Operating torque | 0.14 N.m NO changing electrical state |
| Signalling type | Steady |
| Service life | 100000 h at rated voltage and 25 °C |
| Surge withstand | 1 kV conforming to IEC 61000-4-5 |
| Fixing collar material | Zamak |
| Shape of signaling unit head | Round |
| contact operation | Slow-break |
| Bulb base | Integral LED |
