MGU3.785.18 | Unica – buzzer – 230V AC – 2 m – clip-in – white
| brands | Schneider Electric |
|---|---|
| Range of product | Unica |
| Product or component type | Buzzer |
| Device presentation | Mechanism |
| Aesthetic name | Unica (standard aesthetic) |
| Device application | Signalling |
| Device mounting | Flush |
| Number of modules | 2 modules |
| Material | ASA + PC: mechanism cover |
| Height | 45 mm |
| Width | 45 mm |
| Depth | 42 mm |
| Embedding depth | 31 mm |
| Net weight | 0.0475 kg |
| Current consumption | 40 mA |
| Type of setting | Volume can be adjusted using a screw |
| Operating time | 0…60 ms |
| Connections - terminals | Screw terminals |
| Acoustic level | Between 76 and 80 dB |
| Cable cross section | 0.75…1.5 mm² flexible cable 0.75…1.5 mm² rigid cable |
| Standards | LV directive EMC directive CE |
| IP degree of protection | IP20 |
| IK degree of protection | IK01 |
| Environmental characteristic | Bleach Liquid soap UV resistant Alcohol Petrol Oil Acetone Window-cleaning fluid |
| Unit Type of Package 7 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.2 cm |
| Package 1 Width | 17.6 cm |
| Package 1 Length | 5.5 cm |
| Package 1 Weight | 40.0 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 12.0 cm |
| Package 2 Width | 12.5 cm |
| Package 2 Length | 17.5 cm |
| Package 2 Weight | 462.0 g |
| 462.0 g | S02 |
| Number of Units in Package 3 | 40 |
| Package 3 Height | 15.0 cm |
| Package 3 Width | 30.0 cm |
| Package 3 Length | 40.0 cm |
| Package 3 Weight | 2.15 kg |
| Sustainable offer status | Green Premium product |
| REACh Regulation | REACh Declaration |
| EU RoHS Directive | Compliant EU RoHS Declaration |
| Mercury free | Yes |
| China RoHS Regulation | China RoHS declaration Product out of China RoHS scope. Substance declaration for your information |
| RoHS exemption information | Yes |
| Environmental Disclosure | Product Environmental Profile |
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 18 months |
