Schneider C11N6TM032L | Circuit breaker, ComPacT NSXm 63N, 50kA/415VAC, 4 poles 3D (neutral not protected), TMD trip unit 32A, EverLink lugs

Schneider C11N6TM032L | Circuit breaker, ComPacT NSXm 63N, 50kA/415VAC, 4 poles 3D (neutral not protected), TMD trip unit 32A, EverLink lugs

Technical Specifications C11N6TM032L

• Product Reference: C11N6TM032L

• Series: ComPacT NSXm 63N

• Device Type: Molded Case Circuit Breaker (MCCB)

• Rated Current (In): 32 Amperes

• Rated Operational Voltage: Up to 415 VAC

• Breaking Capacity: 50 kA at 415 VAC

• Number of Poles: 4 poles (3D – 3 protected phases + switched, non-protected neutral)

• Trip Unit Type: TMD (Thermal Magnetic)

• Neutral Protection: Neutral not protected, but switched

• Connection Type: EverLink lugs

• Mounting Mode: Fixed

• Standards Compliance: IEC 60947-2

• Operating Frequency: 50/60 Hz

• Control Type: Manual toggle operation

Key Features

• High Fault Interruption Capability: With a 50 kA breaking capacity, this breaker provides strong protection in demanding fault conditions.

• Thermal-Magnetic Trip Unit: Built-in protection against overloads and short-circuits ensures safe system operation.

• EverLink Lug Technology: Patented EverLink connections maintain tight, stable cable connections, reducing risk of overheating and loosening due to vibration.

• 4-Pole 3D Switching: Three protected phases and one switched (but unprotected) neutral for enhanced system safety.

• Compact Design: Small frame size fits easily into space-constrained panels while offering robust performance.

• Status Indication: ON, OFF, and TRIPPED positions are clearly indicated for fast, easy diagnostics.

• Accessory Ready: Compatible with a wide range of optional accessories including auxiliary contacts, shunt trips, and under-voltage releases.

Applications

• Industrial Panels: Used in protection of machinery, control circuits, and automated systems.

• Commercial Power Distribution: Suitable for sub-panels in shopping centers, hotels, office buildings, and retail outlets.

• Critical Infrastructure: Ideal for applications in hospitals, data centers, transport facilities, and utilities.

• Renewable Energy Systems: Applicable in solar PV installations and wind energy systems where reliable and high-capacity protection is needed.

• Backup and Emergency Systems: Provides protection and isolation for generators and backup power circuits.
