Schneider LV510332 | circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 32 A rating thermal magnetic TM-D trip unit, 3P 3d

Schneider LV510332 | circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 32 A rating thermal magnetic TM-D trip unit, 3P 3d

Technical Specifications

• Model Number: LV510332
• Series: EasyPact CVS
• Breaker Type: Molded Case Circuit Breaker (MCCB)
• Rated Current: 32A
• Frame Size: CVS100F
• Number of Poles: 3P (Three-Pole)
• Breaking Capacity: 36 kA at 415V AC
• Trip Unit Type: Thermal-Magnetic (TM-D)
• Protection Functions: Overload (thermal) and short-circuit (magnetic) protection
• Mounting Type: Fixed mounting
• Operating Voltage: Up to 415V AC
• Compliance: IEC 60947-2

Key Features

1. Strong Overcurrent Protection:

   • Thermal protection safeguards against overload conditions.
   • Magnetic protection quickly responds to short circuits, preventing damage to equipment.

2. High Breaking Capacity (36 kA at 415V AC):

   • Ensures safe disconnection in the event of a fault, making it ideal for demanding environments.

3. Durable and Compact Design:

   • Built to withstand industrial and commercial electrical conditions while maintaining a space-saving form factor.

4. Three-Pole (3P) Configuration:

   • Designed for three-phase electrical systems, ensuring balanced and reliable power distribution.

5. Thermal-Magnetic TM-D Trip Unit:

   • Provides precise and efficient protection tailored for various load conditions.

6. Compliance with IEC Standards:

   • Meets IEC 60947-2 requirements, ensuring high safety and reliability.

Applications

• Industrial Facilities: Used in factories and manufacturing plants for circuit protection.
• Commercial Buildings: Ideal for offices, shopping centers, and hotels.
• Power Distribution Panels: A key component in electrical distribution systems.
• Renewable Energy Systems: Suitable for solar and other renewable energy applications.
• Infrastructure Projects: Perfect for public utilities and large-scale electrical installations.
