Technical Specifications:

• Rated Current (In): 500 A

• Breaking Capacity: 36 kA at 415V AC

• Trip Unit Type: TM-D (Thermal Magnetic – fixed settings)

• Number of Poles: 3 (suitable for three-phase systems without neutral)

• Mounting Type: Panel or base mounting

• Operating Frequency: 50/60 Hz

• Conformity Standards: IEC 60947-2

Key Features:

• High breaking capacity for enhanced fault protection

• Fixed thermal and magnetic trip settings for reliable protection

• Robust design for heavy-duty industrial applications

• Compact frame size for space-saving installation

• Engineered for simplicity, reliability, and cost-effectiveness

Common Applications:

• Main incoming circuit protection in industrial switchboards

• Protection for large motors and heavy loads

• Distribution boards in commercial and manufacturing facilities

• Feeder or sub-main protection in power distribution systems
