SMV750I-GR | APC Easy UPS 1 Ph Line Interactive, 750VA, Tower, 230V, 4 Schuko CEE 7 outlets, AVR, LCD
| brands | Schneider Electric |
|---|---|
| Lead time | Usually in Stock |
| Main Input Voltage | 230 V |
| Input Connection Type | IEC 60320 C14 |
| Main Output Voltage | 230 V |
| Rated power in W | 525 W |
| Rated power in VA | 750 VA |
| Number of cables | 1 |
| output connection type | 4 Schuko CEE 7 |
| Mounting preference | No preference |
| Mounting mode | Not rack-mountable |
| Two post mountable | 0 |
| USB compatible | No |
| Colour | Black |
| Input voltage limits | 165…290 V |
| Output frequency | 50/60 Hz +/- 1 Hz unsynchronised |
| UPS type | Line interactive |
| Wave type | Sine wave |
| Crest factor | 3:01 |
| Graph display | 1 |
| Storage Relative Humidity | 0…95 % non-condensing |
| Storage altitude | 0…15000 m |
| Acoustic level | 45 dBA |
| Surge energy rate | 190 J |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| 1 | 33.9 cm |
| Package 1 Width | 27.2 cm |
| Package 1 Length | 50.8 cm |
| Package 1 Weight | 16.6 kg |
| REACh Regulation | REACh Declaration |
| EU RoHS Directive | Compliant EU RoHS Declaration |
| Mercury free | Yes |
| RoHS exemption information | Yes |
| China RoHS Regulation | China RoHS declaration Pro-active China RoHS declaration (out of China RoHS legal scope) |
| WEEE | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins |
| Warranty | 2 years repair or replace |
| Transfer time | 2-6 ms typical : 12 ms maximum |
| Operating altitude | 0…3000 m |
| Standards | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
| Product certifications | CE |
| Run Time | View Runtime Graph |
| Number of battery free slots | 0 |
| Battery type | Lead-acid battery |
| Battery voltage | 24 V |
| Battery recharge time | 4 h |
| Battery life | 3…5 year(s) |
| Battery charger power | 33 W rated |
| Replacement battery | APCRBCV206 |
| Extended runtime | 0 |
| Redundant | No |
| UPS size | WS |
| Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
