Schneider LV510335 | circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 3P 3d

Schneider LV510335 | circuit breaker EasyPact CVS100F, 36 kA at 415 VAC, 63 A rating thermal magnetic TM-D trip unit, 3P 3d

Technical Specifications

• Model Number: LV510335
• Series: EasyPact CVS
• Breaker Type: Molded Case Circuit Breaker (MCCB)
• Rated Current: 63A
• Frame Size: CVS100F
• Number of Poles: 3P (Three-Pole)
• Breaking Capacity: 36 kA at 415V AC
• Trip Unit Type: Thermal-Magnetic (TM-D)
• Protection Functions: Overload (thermal) and short-circuit (magnetic) protection
• Voltage Rating: Suitable for 415V AC systems
• Mounting Type: Fixed mounting
• Compliance: Conforms to IEC 60947-2

Key Features

1. Reliable Overcurrent Protection:

   • Thermal protection offers overload defense, while magnetic protection provides fast reaction to short circuits, ensuring equipment safety.

2. High Breaking Capacity (36 kA at 415V AC):

   • Capable of handling fault currents up to 36 kA, this breaker provides reliable protection in high-demand applications.

3. Robust and Compact Design:

   • Built for high durability and designed to save space, it’s ideal for industrial and commercial environments.

4. Three-Pole (3P) Configuration:

   • Ideal for three-phase electrical systems, providing balanced and efficient circuit protection.

5. Thermal-Magnetic TM-D Trip Unit:

   • Features precise thermal and magnetic protection to handle different fault conditions, ensuring protection against overloads and short circuits.

6. Compliant with International Standards:

   • Meets the strict requirements of IEC 60947-2, ensuring safety, performance, and compliance with global standards.

Applications

• Industrial Applications: Ideal for use in factories, manufacturing plants, and heavy machinery.
• Commercial Buildings: Suitable for offices, shopping malls, and business centers requiring reliable circuit protection.
• Power Distribution Systems: Perfect for electrical panels and distribution boards to ensure safe power management.
• Renewable Energy Installations: Can be used in solar power systems and other renewable energy applications.
• Infrastructure Projects: Essential for public utilities and large-scale installations requiring high capacity protection.
