Schneider SSRDF8S45A1 | Solid state relay, HARMONY Relay, DIN rail mount, input 90…280 V AC, output 24 280 V AC, 45 A

Schneider SSRDF8S45A1 | Solid state relay, HARMONY Relay, DIN rail mount, input 90…280 V AC, output 24 280 V AC, 45 A

Technical Specifications:

1. Input Voltage Range: The relay accepts an input voltage range of 90 to 280V AC, making it compatible with standard AC control circuits in industrial settings. This wide input range ensures flexibility in integration with various control devices, including PLCs and microcontrollers.

2. Output Voltage Range: The SSRD8S45A1 can control AC loads within the 24-280V AC output voltage range, making it versatile and suitable for a wide variety of industrial applications. This range ensures that the relay can handle different types of AC-powered equipment and devices.

3. Current Rating: This solid-state relay is rated for 45A, meaning it can manage high current loads effectively. With this current handling capability, the SSRDF8S45A1 is ideal for industrial environments where substantial power needs to be switched, such as in heating systems, motors, and other large machinery.

4. DIN Rail Mounting: Designed for DIN rail mounting, this relay can be easily installed in standard control panels and industrial enclosures. The DIN rail design ensures a neat, secure, and compact installation, contributing to efficient space utilization within the control panel.

5. Zero-Crossing Detection: The SSRDDF8S45A1 features zero-crossing detection, a technology that minimizes electrical noise and enhances the efficiency of switching by controlling the relay operation at the point where the AC waveform crosses zero voltage. This helps extend the life of the relay and reduces the risk of electrical interference in the system.

6. Solid-State Operation: As a solid-state relay, the SSRDF8S45A1 has no moving parts, which makes it more durable and reliable than traditional mechanical relays. It can switch faster, lasts longer, and operates with less maintenance, offering better performance and longevity in industrial applications.

7. Thermal Management: The relay includes an efficient thermal management system, designed to maintain safe operating temperatures even when handling high-power loads. This feature prevents overheating, ensuring stable operation and a longer lifespan for the relay and the equipment it controls.

8. LED Status Indicators: The SSRDF8S45A1 comes with LED indicators that provide real-time feedback about the relay’s operating condition. These indicators make it easy to monitor the relay’s performance and troubleshoot any potential issues.

Features:

1. Wide Input Voltage Range: With an input range of 90 to 280V AC, the SSRDDF8S45A1 is suitable for a broad range of industrial power systems, providing flexibility in how the relay is integrated into different setups.

2. High Current Rating: The 45A current rating ensures that the relay can handle substantial loads, making it ideal for heavy-duty applications where high-power AC devices need to be controlled.

3. DIN Rail Mounting: The DIN rail mounting design provides easy and secure installation in control panels and automation systems, simplifying the process of integrating the relay into existing electrical panels.

4. Zero-Crossing Technology: The relay incorporates zero-crossing detection technology, improving switching efficiency, reducing noise, and ensuring smooth, reliable operation for both the relay and the connected loads.

5. Solid-State Design: As a solid-state relay, it features no mechanical parts, reducing wear and tear. This design results in faster switching speeds, higher reliability, and a longer operational lifespan compared to traditional electromechanical relays.

6. Thermal Management: The relay’s efficient thermal management helps prevent overheating and ensures consistent performance even under heavy loads.

7. LED Status Indicators: The LED status indicators allow users to easily monitor the operational state of the relay, providing clear visual feedback for troubleshooting and maintenance.

Applications:

The Schneider SSRDF8S45A1 solid-state relay is designed for a variety of high-power switching applications, including:

• Heating Systems: Ideal for controlling electric heating elements in industrial heating applications, such as furnaces, ovens, and temperature regulation systems.

• Motor Control: Perfect for motor control in applications such as industrial machinery, pumps, conveyors, and compressors.

• Lighting Control: Suitable for controlling high-power lighting systems in industrial, commercial, and outdoor environments.

• Temperature Control: Used in temperature regulation systems for managing heating and cooling elements in industrial settings.

• Factory Automation: Offers precise and reliable switching for automated systems that require the control of heavy-duty AC devices.

• Energy Management: Can be integrated into energy management systems for monitoring and controlling high-power equipment in industrial plants or large facilities.

• Industrial AC Load Switching: Can be used to control other AC-powered devices like pumps, fans, or compressors in various industrial applications.
